2. Technical parameters
Item |
Specifications |
The mold diameter |
φ30mm (optional φ22mm, 45mm) |
Heater Power |
560 w |
Temperature range |
0 ~ 200℃ adjustable |
Time range |
0 ~ 30 min |
Pressure mode |
Automatic (motor loading) |
Cooling way |
Water cooling (optional chiller) |
Operation and display mode |
Touch screen |
Mounting application |
Editable mounting process library, can store 99 sets of mounting process |
Program input/output |
U disk |
Working mode |
Automatic and manual can be switched |
Total power: |
1000W |
Power supply |
AC220V 50HZ |
Overall dimensions |
530 * 430 * 410 mm |
Weight |
66Kg |
