Application:
This series of products are mainly used for the compression test of special materials such as metal components, building components and petroleum proppants, and can also be used for the pressure test identification of jacks.
Standards:
It is conformed to EN 12390-3, 12390-4; BS 1881,ASTM E4, ASTM C139, ISO7500-1, EN10002-2, BS 1610, DIN51220, C1231 –AASHTO T22 -NF P18-411 -UNE 83304, 7242 etc.
Main Specifications:
Model |
HLCTM-5000 |
Max. Load |
5000kN |
Control method |
Computer auto control loading process |
Test class |
1 class |
Load measuring range |
4-100% of F.S |
Load accuracy |
±1.0% |
Displacement measuring range |
0~80mm |
Displacement resolution |
0.001 |
Upper and lower compression platen (mm) |
600mm×600mm |
Piston stroke(mm) |
80 |
Distance between upper and lower plate |
1000mm |
Power supply |
AC380V/220V |
