1.Product Features.
-Large voltage and current range, can meet the polishing and corrosion of various materials at the same time;
-Realize constant current and constant voltage working mode;
- Dc 0~100V / 0~6A, current voltage value can be customized;
- Voltage and current have rough and fine tuning switching function, can accurately and stably set the voltage current value;
- Voltage and current regulation, display precision two decimal places;
- Low ripple and high stability of electrical signal;
- Overvoltage, overheat and undervoltage protection of power input;
-The polishing/corrosion area of the sample can be controlled (the opening diameter of the sample hood is 15mm, 20mm, 30mm);
- Control polishing/corrosion working time;
- The agitator ensures uniform polishing/corrosion medium and uniform surface environment of samples.
-The working voltage and current can be input into the computer for further data analysis and research (optional items: RS232, RS485, wireless connection and computer communication are optional).
2.Technical Parameters.
Item |
Specifications |
Working voltage |
AC220V 50 hz |
Electrolytic output |
DC 0~100V / 0~6A, continuously adjustable, digital display; |
Voltage and current regulation, display accuracy |
Voltage 0.01V/ current 0.001A |
Constant temperature range |
At room temperature to 100 ℃ + / - 1 ℃ |
Time display |
Working hours can be set |
Container capacity |
800 ml |
Cooling system |
Cooling coil, external tap water cooling |
Electric box size |
292 * 380 * 120 mm |
Magnetic agitator size |
240 * 190 * 130 mm |
Total power |
900 w |
Total weight |
15 kg |
