HLB-62.5MDX AutomaticTurret Small Load Brinell Hardness Tester

HLB-62.5MDX AutomaticTurret Small Load Brinell Hardness Tester
HLB-62.5MDX AutomaticTurret Small Load Brinell Hardness Tester
HLB-62.5MDX AutomaticTurret Small Load Brinell Hardness Tester

Product introduction

1) Electric loading, High accuracy sensor, with special closed-loop control system, each force is automatically compensated.

2) Automatic turret, objectives and indenter can switch freely, testing point is positioning automatically, auto loading,auto unloading.With two objectives outer lighting,almost solve the problem which can not test when indentation is too small or too bi, outer lighting make the indentation more clear and precise.

3) Objective with digital encoder, when test D1,D2 value, LCD display can show hardness value ,D1 and D2 value directly.

4) Can calibrate according to standard block and length scale.

5) Test force can self-correct though standard dynamometer.

6) Conversion between Rockwell and Brinell hardness value.

7) All data is saved in USB disk as EXCEL format.


Technical parameters

Model

HLB-62.5MDX

Brinell scale

HBW1/1HBW1/2.5HBW1/5HBW2.5/6.25HBW1/10HBW2.5/15.625HBW5/25HBW1/30HBW2.5/31.25HBW2.5/62.5HBW5/62.5

Test forceKgf

1Kgf(9.8N)2.5Kgf(24.5N)5Kgf(49N)6.25Kgf(61.29N)10Kgf(98N)

15.625Kgf(153.23N)25Kgf(245.2N)30Kgf(294N)31.25Kgf(306.47N)

62.5Kgf(612.94N)

Carried standard

BSEN 6506, ISO 6506, ASTM E10, GB/T231

Min measuring unit

0.1um

Hardness resolution

0.1HBW

Test microscope magnification

50X100X

Duration time

099S

Data output

LCD display

Data storage

data is saved in USB disk as EXCEL format

Max Height of Specimen

180mm

Distance of Indenter to outer wall

160mm

Size

590×200×680mm

Weight

50kg

Power

AC220+5%,5060Hz
