•Compact design requires less room in the lab and oil free drive system not only keep the lab clean but also low noisy.
•Stable and reliable high intensity structure load frame with extended tabletop provides extra area for placement of additional jigs.
•Real time display software ensures the accurate track of testing process.
•Pre-built test methods for cement mortar, concrete prism, dimension stone and user configurable test methods are available.
•Overload and over travel protection available for secure operator and machine.
•Custom report template available.
•Easily expand test solutions at a later date with hardware and software options.
Technical Specifications
Model |
WHY-300 |
WHY-300A |
WHY-300/10 |
WHY-300/10A |
|
Load capacity |
kN |
300 |
300 |
300&10 |
300&10 |
Accuracy |
% |
CLASS 1 (ISO 7500-1) |
|||
Measuring range |
% |
2%~100% |
|||
Actuator stroke |
mm |
100 |
|||
Speed range |
mm/min |
0.1-50 |
|||
Dimensions |
mm |
1000*800*1600 |
1000*800*1600 |
1000*800*1600 |
1200*1000*1600 |
Weight |
kg |
720 |
720 |
720 |
860 |
Notes: 1. Load weighing system meets or exceeds the requirements of the following standards: ASTM E4, EN 10002 -2, BS 1610, DIN 51221, ISO 7500-1. 2. Specifications subject to change without notice. 3. Custom jigs and power system available. Storage Temperature Range: -10 to 45°C Humidity Range: 10% to 90% non-condensing, wet bulb method. Power: standard optional voltages 220/ 240 VAC, 50~60 Hz; power must be free of spikes and surges exceeding 10% of the nominal voltage. |
